Machine Features
- Half Mirror Finishing
- Heavy Duty Structure HT250
- 40% Faster Than PNC
- C-Tech Taiwan Controller
Machine Specification
| Table travel to working table | mm | 450*350 |
| Working table dimension | mm | 700*400 |
| Z axis travel | mm | 210 |
| Z Travel of machine head | mm | 235 |
| Max and Min height of spindle end | mm | 660/220 |
| Weight of machine body | kg | 1500 |
| Dimension of oil tank | mm | 750*1150*530 |
| Max load of working table | kg | 800 |
| Max weight of electrode | kg | 50 |
| Dimension of working tank | mm | 1065*640*450 |
| Dimension of machine | mm | 2100*1300 |
| Table travel to working table | mm | 500*400 |
| Working table dimension | mm | 800*450 |
| Z axis travel | mm | 220 |
| Z Travel of machine head | mm | 260 |
| Max and Min height of spindle end | mm | 690\220 |
| Weight of machine body | kg | 1700 |
| Dimension of oil tank | mm | 1100*1400*530 |
| Max load of working table | kg | 1000 |
| Max weight of electrode | kg | 50 |
| Dimension of working tank | mm | 1160*690*500 |
| Dimension of machine | mm | 2400*1450 |
| Table travel to working table | mm | 600*500 |
| Working table dimension | mm | 900*500 |
| Z axis travel | mm | 220 |
| Z Travel of machine head | mm | 260 |
| Max and Min height of spindle end | mm | 800/340 |
| Weight of machine body | Kg | 2100 |
| Dimension of oil tank | mm | 1100*1900*510 |
| Max load of working table | kg | 1000 |
| Max weight of electrode | kg | 50 |
| Dimension of working tank | mm | 1320*800*500 |
| Dimension of machine | mm | 2500*1900 |
| Table travel to working table | mm | 800*600 |
| Working table dimension | mm | 1200*700 |
| Z axis travel | mm | 260 |
| Z Travel of machine head | mm | 280 |
| Max and Min height of spindle end | mm | 950/410 |
| Weight of machine body | kg | 3600 |
| Dimension of oil tank | mm | 1400*2100*510 |
| Max load of working table | kg | 2000 |
| Max weight of electrode | kg | 50 |
| Dimension of working tank | mm | 1730*1020*600 |
| Dimension of machine | mm | 2750*2100 |
