Machine Features
- Mirror Finishing
- 3 Axis Working Together
- Heavy Duty Structure HT300
- Servo Motor With 0.002 Accuracy
- 70% Faster Than ZNC OR PNC
- Carbide & Titanium Support
- Orbital Mode For Helix
- Tunnel Gate Stander
- Windows Touch Screen For Controller
Machine Specification
| 45S+ | ||
| X Axis travel | MM | 450 |
| Y Axis travel | MM | 300 |
| Z Axis travel | MM | 320 |
| Working table dimension | MM | 700*400 |
| Max weight of workpiece | KG | 400 |
| Max weight of electrode | KG | 25 |
| Distance from spindle end to working table | MM | 585 |
| Dimension of working tank on table | MM | 1200*680*440 |
| Highest oil level | MM | 290 |
| Dimension of machine | MM | 2560*2300*2306 |
| Max machining current | A | 50 |
| Best surface finish | UM | < 0.2 |
| Min. electrode wear | % | < 0.1 |
| Max machining speed | MM3/MIN | > 500 |
| Control axes | / | 3-axis simultaneous control |
| Display | / | 15’touch screen (TFT-LCD) |
| Door open type | / | Manual lifting door |
| Capacity of oil tank | L | 590 |
| Weight of machine | Kg | 2600 |
| 60S+ | ||
| X Axis travel | MM | 600 |
| Y Axis travel | MM | 400 |
| Z Axis travel | MM | 350 |
| Working table dimension | MM | 900*600 |
| Max weight of workpiece | KG | 400 |
| Max weight of electrode | KG | 100 |
| Distance from spindle end to working table | MM | 700 |
| Dimension of working tank on table | MM | 1640*960*515 |
| Highest oil level | MM | 380 |
| Dimension of machine | MM | 2700*2900*2400 |
| Max machining current | A | 50 |
| Best surface finish | UM | < 0.2 |
| Min. electrode wear | % | < 0.1 |
| Max machining speed | MM3/MIN | > 500 |
| Control axes | / | 3-axis simultaneous control |
| Display | / | 15’touch screen (TFT-LCD) |
| Door open type | / | Manual lifting door |
| Capacity of oil tank | L | 1100 |
| Weight of machine | Kg | 4000 |
