Machine Features
- High Speed Drilling
- Heavy Duty Structure
- From 0.3 mm To 3.0 mm
- Convenient Controller
- Electronical Pump
- 8mpa Water Pressure
- Recycle Tank Optional
- Comes with 150 electrode and tool box
Machine Specification
| Technical terms | Unit | DZ430i |
| Table travel | Mm | 400×300 |
| Machine head travel | Mm | 250 |
| Z axis travel(spindle servo stroke) | Mm | 380 |
| Max. speed of spindle( mm/min) | 1500 | |
| Rotation speed of the spindle (RPM) | 0-200 adjustable | |
| Working table size (mm) | 440×320 | |
| Power supply | 3 phase 380v/50hz | |
| Control axis | X,Y,Z | |
| Max. worktable load ( kg) | 300 | |
| Dimension of machine ( W*L*H) | 1000×2000×1000 | |
| Machine weight | kg | 700 |
| Technical terms | Unit | DZ435 |
| Table travel | Mm | 450×350 |
| Machine head travel | Mm | 250 |
| Z axis travel(spindle servo stroke) | Mm | 380 |
| Max. speed of spindle( mm/min) | 1500 | |
| Rotation speed of the spindle (RPM) | 0-200 adjustable | |
| Working table size (mm) | 520×380 | |
| Power supply | 3 phase 380v/50hz | |
| Control axis | X,Y,Z | |
| Max. worktable load ( kg) | 380 | |
| Dimension of machine ( W*L*H) | 1200×2100×1000 | |
| Machine weight | kg | 860 |
| Technical terms | Unit | DZ640 |
| Table travel | Mm | 600×400 |
| Machine head travel | Mm | 250 |
| Z axis travel(spindle servo stroke) | Mm | 380 |
| Max. speed of spindle( mm/min) | 1500 | |
| Rotation speed of the spindle (RPM) | 0-200 adjustable | |
| Working table size (mm) | 700×450 | |
| Power supply | 3 phase 380v/50hz | |
| Control axis | X,Y,Z | |
| Max. worktable load ( kg) | 380 | |
| Dimension of machine ( W*L*H) | 1400×2100×1200 | |
| Machine weight | Kg | 960 |
| Technical terms | Unit | DZ850 |
| Table travel | Mm | 800×500 |
| Machine head travel | Mm | 250 |
| Z axis travel(spindle servo stroke) | Mm | 380 |
| Max. speed of spindle( mm/min) | 1500 | |
| Rotation speed of the spindle (RPM) | 0-200 adjustable | |
| Working table size (mm) | 1050×550 | |
| Power supply | 3 phase 380v/50hz | |
| Control axis | X,Y,Z | |
| Max. worktable load ( kg) | 800 | |
| Dimension of machine ( W*L*H) | 1800×2200×1600 | |
| Machine weight | Kg | 1600 |
