Machine Features
• X-Y Servo Motor Panasonic
• UVZ Stepper Motor {15-Degrees}
• Electricity Stabilizer
• Heavy Duty Structure
• Wire Tension
• Auto-CUT Convenient System
• Optional { 30 Degree Taper – Aluminum Cutting }
Machine Specification
| Name | DK7745 | |
|---|---|---|
| X×Y Stroke | Mm | 450 x 550 |
| U×V Stroke | Mm | Adjusted |
| Workable Dimension | Mm | 500 x 785 |
| Input Voltage | V/Hz | 220-380\50 |
| Max Cut Taper | 0/Mm | 6:60 |
| Best Surface Finish | Um | Ra<0.8(O20,SKD11,THICKNESS20MM, MULTI-CUT) |
| Max Cut Current | A | 6 |
| Max Load Or Worktable | Kg | 500 |
| Weight Of Machine | Kg | 2000 |
| Name | DK7750 | |
|---|---|---|
| X×Y Stroke | Mm | 500 x 630 |
| U×V Stroke | Mm | Adjusted |
| Workable Dimension | Mm | 600 x 900 |
| Input Voltage | V/Hz | 220-380\50 |
| Max Cut Taper | 0/Mm | 6:60 |
| Best Surface Finish | Um | Ra<0.8(O20,SKD11,THICKNESS20MM, MULTI-CUT) |
| Max Cut Current | A | 6 |
| Max Load Or Worktable | Kg | 800 |
| Weight Of Machine | Kg | 2300 |
| Name | DK7763 | |
|---|---|---|
| X×Y Stroke | Mm | 630 x 800 |
| U×V Stroke | Mm | Adjusted |
| Workable Dimension | Mm | 600 x 1100 |
| Input Voltage | V/Hz | 220-380\50 |
| Max Cut Taper | 0/Mm | 6:60 |
| Best Surface Finish | Um | Ra<0.8(O20,SKD11,THICKNESS20MM, MULTI-CUT) |
| Max Cut Current | A | 6 |
| Max Load Or Worktable | Kg | 1000 |
| Weight Of Machine | Kg | 4500 |
| Name | DK7780 | |
|---|---|---|
| X×Y Stroke | Mm | 800 x 1000 |
| U×V Stroke | Mm | Adjusted |
| Workable Dimension | Mm | 600 x 1100 |
| Input Voltage | V/Hz | 220-380\50 |
| Max Cut Taper | 0/Mm | 6:45 |
| Best Surface Finish | Um | Ra<0.8(O20,SKD11,THICKNESS20MM, MULTI-CUT) |
| Max Cut Current | A | 6 |
| Max Load Or Worktable | Kg | 2500 |
| Weight Of Machine | Kg | 5500 |
