Machine Features
- Fanuc Controller
- Schneider electrical component
- Taiwan Line Liner guide & Ball Screw
- Taiwan Spindle 10,000 RBM With Oil Chiller
- Heavy Duty Structure HT300
- Auto Power Off
- Chip Conveyor
- 4th Axis 255MM
- 12,000 RBM Spindle
Machine Specification
|
V855 |
||
| Work Table Dimensions | MM | 1000×550 |
| Max load of work table | KG | 500 |
| T Groove | MM | 5x18x90 |
| X Axis Travel | MM | 830 |
| Y Axis Travel | MM | 550 |
| Z Axis Travel | MM | 550 |
| Spindle end to worktable | MM | 120-670 |
| Spindle Center to Column | MM | 565 |
| Spindle Type | BT40 | |
| Spindle Speed | RBM | 10000/12000 |
| Machine Dimensions | MM | 2500x2400x2650 |
| Spindle Drive | Belt/Direct | |
| Spindle Power | KW | /1115 |
| Motor Torque XYZ | N.M | 20/20/20 |
| CNC System | Fanuc -0I MF | |
| Rapid Feed XYZ | MM | 36/36/36 |
| Magazine Capacity | 24 | |
| Positioning Accuracy | MM | 0.008 |
| Repositioning Accuracy | MM | 0.005 |
| Air Supply | KG/CM3 | 6 |
| Machine Weight | KG | 5800 |
|
V1160 |
||
| Work Table Dimensions | MM | 1300×600 |
| Max load of work table | KG | 800 |
| T Groove | MM | 5x18x100 |
| X Axis Travel | MM | 1100 |
| Y Axis Travel | MM | 600 |
| Z Axis Travel | MM | 600 |
| Spindle end to worktable | MM | 120-720 |
| Spindle Center to Column | MM | 650 |
| Spindle Type | BT40 | |
| Spindle Speed | RBM | 10000 |
| Machine Dimensions | MM | 3160x2600x2850 |
| Spindle Drive | Belt/Direct | |
| Spindle Power | KW | 15 |
| Motor Torque XYZ | N.M | 20/20/20 |
| CNC System | Fanuc -0I MF | |
| Rapid Feed XYZ | MM | 30/30/30 |
| Magazine Capacity | 24 | |
| Positioning Accuracy | MM | 0.008 |
| Repositioning Accuracy | MM | 0.005 |
| Air Supply | KG/CM3 | 6 |
| Machine Weight | KG | 7000 |
|
V1266 |
||
| Work Table Dimensions | MM | 1300×650 |
| Max load of work table | KG | 800 |
| T Groove | MM | 5x18x125 |
| X Axis Travel | MM | 1200 |
| Y Axis Travel | MM | 700 |
| Z Axis Travel | MM | 700 |
| Spindle end to worktable | MM | 120-820 |
| Spindle Center to Column | MM | 700 |
| Spindle Type | BT40 | |
| Spindle Speed | RBM | 10000/12000 |
| Machine Dimensions | MM | 3500x2700x2700 |
| Spindle Drive | Belt/Direct | |
| Spindle Power | KW | 11/15 |
| Motor Torque XYZ | N.M | 20/20/20 |
| CNC System | Fanuc -0I MF | |
| Rapid Feed XYZ | MM | 30/30/30 |
| Magazine Capacity | 24 | |
| Positioning Accuracy | MM | 0.008 |
| Repositioning Accuracy | MM | 0.005 |
| Air Supply | KG/CM3 | 6 |
| Machine Weight | KG | 8000 |
|
V1580 |
||
| Work Table Dimensions | MM | 1700×800 |
| Max load of work table | KG | 1500 |
| T Groove | MM | 5x22x135 |
| X Axis Travel | MM | 1500 |
| Y Axis Travel | MM | 800 |
| Z Axis Travel | MM | 700 |
| Spindle end to worktable | MM | 130-830 |
| Spindle Center to Column | MM | 810 |
| Spindle Type | BT50 | |
| Spindle Speed | RBM | 8000/12000 |
| Machine Dimensions | MM | 4300x3500x3500 |
| Spindle Drive | Belt/Direct | |
| Spindle Power | KW | 15/18.5(11/15) |
| Motor Torque XYZ | N.M | 27/27/27 |
| CNC System | Fanuc -0I MF | |
| Rapid Feed XYZ | MM | 20/20/20 |
| Magazine Capacity | 24 | |
| Positioning Accuracy | MM | 0.012 |
| Repositioning Accuracy | MM | 0.008 |
| Air Supply | KG/CM3 | 6 |
| Machine Weight | KG | 12500 |
